#include "stdafx.h"
#include "glFont.h"
#include <gl\gl.h>
#include <gl\glu.h>
#include "gl\glaux.h"
#include <atlstr.h>
CGlFont::CGlFont()
{
m_hFont=NULL;
InitFont("宋体",10);
m_X = 0;
m_Y = 0;
m_dHeight = 0;
m_fExtrusion = 0.1f;
m_rotateTheta = 0.0;
m_iDisplayList = 0;
m_red =255;
m_blue = 255;
m_green = 255;
}
CGlFont::~CGlFont()
{
}
LOGFONT CGlFont::GetLogFont()
{
LOGFONT lf;
GetObject(m_hFont,sizeof(LOGFONT),&lf);
return lf;
}
void CGlFont::DeleteFont()
{
if(m_hFont)
{
DeleteObject(m_hFont);
m_hFont=NULL;
}
}
bool CGlFont::InitFont(LOGFONT &lf)
{
DeleteFont();
m_hFont=CreateFontIndirect(&lf);
if( m_hFont )return true;
else return false;;
}
bool CGlFont::InitFont(char *fontName, int height)
{
DeleteFont();
m_hFont = CreateFont(
-height, //< lfHeight 字体高度
0, //< lfWidth 字体宽度
0, //< lfEscapement 字体的旋转角度 Angle Of Escapement
0, //< lfOrientation 字体底线的旋转角度Orientation Angle
FW_THIN, //< lfWeight 字体的重量
FALSE, //< lfItalic 是否使用斜体
FALSE, //< lfUnderline 是否使用下划线
FALSE, //< lfStrikeOut 是否使用删除线
DEFAULT_CHARSET, //< lfCharSet 设置字符集
OUT_TT_PRECIS, //< lfOutPrecision 输出精度
CLIP_DEFAULT_PRECIS, //< lfClipPrecision 裁剪精度
ANTIALIASED_QUALITY, //< lfQuality 输出质量
FF_DONTCARE|DEFAULT_PITCH, //< lfPitchAndFamily Family And Pitch
fontName); //< lfFaceName 字体名称
if(m_hFont)return true;
else return false;
}
void CGlFont::Draw2DText(char *string)
{
if(strlen(string)<=0)return;
//HDC hDC=wglGetCurrentDC();
HDC hDC = ::CreateCompatibleDC(NULL);
HFONT hOldFont=NULL;
hOldFont=(HFONT)SelectObject(hDC,m_hFont);
if(!hOldFont)
{
return;
}
glRasterPos2f(m_X, m_Y);
DWORD dwChar;
int ListNum;
for(size_t i=0;i<strlen((char *)string);i++)
{
if(IsDBCSLeadByte(string[i]))
{
dwChar=((unsigned char)string[i])*0x100+(unsigned char)string[i+1];
i++;
}
else
{
dwChar=string[i];
}
ListNum=glGenLists(1);
wglUseFontBitmaps(hDC,dwChar,1,ListNum);
glCallList(ListNum);
glDeleteLists(ListNum,1);
}
SelectObject(hDC,hOldFont);
::DeleteDC(hDC);
}
map<UINT,FontDesc> CGlFont::m_sglFontList;
void CGlFont::Draw3DText(const char *string)
{
if(strlen(string)<=0)
return;
GLYPHMETRICSFLOAT pgmf[1];
HDC hDC=wglGetCurrentDC();
//设置当前字体
HFONT hOldFont=NULL;
hOldFont=(HFONT)SelectObject(hDC,m_hFont);
if(!hOldFont)
{
return;
}
DWORD dwChar;
int ListNum;
int iNum=strlen((char *)string);
m_iDisplayList=glGenLists(1);
glPushMatrix();
for(size_t i=0;i<strlen((char *)string);i++)
{
if(IsDBCSLeadByte(string[i]))//是否为中文
{
dwChar=((unsigned char)string[i])*0x100+(unsigned char)string[i+1];
i++;
}
else
{
dwChar=string[i];
}
//不同的文字在文字描述表中只出现一次,如“我是中国中国”,重复的中和国只出现一次,这样大大提高了速度
if (m_sglFontList.find(dwChar) == m_sglFontList.end())
{
GLuint newID = glGenLists(1);
wglUseFontOutlines(hDC,dwChar,1,newID,0.0,m_fExtrusion,WGL_FONT_LINES,pgmf);
FontDesc font;
font.flyfloat = pgmf[0];
font.iList = newID;
m_sglFontList[dwChar] = font;
}
}
glPopMatrix();
SelectObject(hDC,hOldFont);
//生成操作列表
glNewList(m_iDisplayList, GL_COMPILE);
glPushMatrix();
glTranslated(m_X,m_Y,0);
glScaled(m_dHeight,m_dHeight,1);
glRotated(m_rotateTheta,0,0,1);
for(size_t i=0;i<strlen((char *)string);i++)
{
if(IsDBCSLeadByte(string[i]))
{
dwChar=((unsigned char)string[i])*0x100+(unsigned char)string[i+1];
i++;
}
else
{
dwChar=string[i];
}
glCallList(m_sglFontList[dwChar].iList);
}
glPopMatrix();
glEndList();
//执行操作表中的内容
glPushMatrix();
glColor3ub((GLbyte)m_red,(GLbyte)m_green,(GLbyte)m_blue);
glCallList(m_iDisplayList);
glPopMatrix();
}
void CGlFont::SetColor(int r, int g, int b)
{
m_red = r;
m_green = g;
m_blue = b;
}
CGlFont glFont;
int Font_Height = 10;
glFont.InitFont(_T("Times new roma"),Font_Height);
int count = 0;
for(float x = -length_area/2-10; x <= length_area/2+80; x +=20)
{
float y = -5.0f;
if (count%5==0)
{
glFont.m_X = (x-9);
glFont.m_Y = (y-20);
glFont.m_dHeight =0.1;
glFont.SetColor(255,255,255);
int temp =count * 20;
CString s;
s.Format("%d",temp);
glFont.Draw2DText(s.GetBuffer());
}
count++;
}
//Y坐标轴系数
count =0;
for (float y = 0; y <= 100; y +=5)
{
float x = -length_area/2-15;
if (count%5==0)
{
glFont.InitFont(_T("Times new roma"),Font_Height);
glFont.m_X = x-190;
glFont.m_Y = y;
glFont.m_dHeight =0.1;
glFont.SetColor(255,255,255);
float temp = (maxHeight*height_scale/4)*(count/5);
CString s;
s.Format("%.4f",temp);
glFont.Draw2DText(s.GetBuffer());
}
count++;
}
ASSERT( hDC != NULL );
