mybatis练习逆向工程时，除了好几次，解决不了，求大神帮忙！！！！！！

[weixin_44348990]

log4j:WARN Fatal parsing error 54 and column 16
log4j:WARN XML 文档结构必须从头至尾包含在同一个实体内。
log4j:ERROR Could not parse url [file:/C:/Users/Administrator/eclipse-workspace/Study/target/classes/log4j.xml].
org.xml.sax.SAXParseException; systemId: file:/C:/Users/Administrator/eclipse-workspace/Study/target/classes/log4j.xml; lineNumber: 54; columnNumber: 16; XML 文档结构必须从头至尾包含在同一个实体内。
at java.xml/com.sun.org.apache.xerces.internal.parsers.DOMParser.parse(Unknown Source)
at java.xml/com.sun.org.apache.xerces.internal.jaxp.DocumentBuilderImpl.parse(Unknown Source)
at org.apache.log4j.xml.DOMConfigurator$2.parse(DOMConfigurator.java:769)
at org.apache.log4j.xml.DOMConfigurator.doConfigure(DOMConfigurator.java:871)
at org.apache.log4j.xml.DOMConfigurator.doConfigure(DOMConfigurator.java:778)
at org.apache.log4j.helpers.OptionConverter.selectAndConfigure(OptionConverter.java:526)
at org.apache.log4j.LogManager.<clinit>(LogManager.java:127)
at org.apache.log4j.Logger.getLogger(Logger.java:117)
at org.mybatis.generator.logging.Log4jImpl.<init>(Log4jImpl.java:30)
at org.mybatis.generator.logging.LogFactory$Log4jLoggingLogFactory.getLog(LogFactory.java:70)
at org.mybatis.generator.logging.LogFactory.getLog(LogFactory.java:43)
at org.mybatis.generator.internal.db.DatabaseIntrospector.<init>(DatabaseIntrospector.java:98)
at org.mybatis.generator.config.Context.introspectTables(Context.java:634)
at org.mybatis.generator.api.MyBatisGenerator.generate(MyBatisGenerator.java:257)
at org.mybatis.generator.api.MyBatisGenerator.generate(MyBatisGenerator.java:139)
at com.neuedu.test.MybatisGenTest.generator(MybatisGenTest.java:29)
at com.neuedu.test.MybatisGenTest.main(MybatisGenTest.java:52)
log4j:WARN No appenders could be found for logger (org.mybatis.generator.internal.db.DatabaseIntrospector).
log4j:WARN Please initialize the log4j system properly.
log4j:WARN See http://logging.apache.org/log4j/1.2/faq.html#noconfig for more info.


代码如下：

package com.neuedu.test;

import java.io.File;
import java.io.IOException;
import java.sql.SQLException;
import java.util.ArrayList;
import java.util.List;

import org.mybatis.generator.api.MyBatisGenerator;
import org.mybatis.generator.config.Configuration;
import org.mybatis.generator.config.xml.ConfigurationParser;
import org.mybatis.generator.exception.InvalidConfigurationException;
import org.mybatis.generator.exception.XMLParserException;
import org.mybatis.generator.internal.DefaultShellCallback;

public class MybatisGenTest {
public void generator() {
	List<String> waList = new ArrayList<String>();
	boolean overwrite = true;
//	指定配置文件
	File configFile = new File("C:\\Users\\Administrator\\eclipse-workspace\\Study\\src\\main\\resources\\config.xml");
	ConfigurationParser configurationParser = new ConfigurationParser(waList);
	Configuration configuration = null;
	MyBatisGenerator myBatisGenerator = null;
	try {
		configuration = configurationParser.parseConfiguration(configFile);
		DefaultShellCallback callback = new DefaultShellCallback(overwrite);
		myBatisGenerator = new MyBatisGenerator(configuration, callback, waList);
		myBatisGenerator.generate(null);
	} catch (IOException e) {
		// TODO Auto-generated catch block
		e.printStackTrace();
	} catch (XMLParserException e) {
		// TODO Auto-generated catch block
		e.printStackTrace();
	} catch (InvalidConfigurationException e) {
		// TODO Auto-generated catch block
		e.printStackTrace();
	} catch (SQLException e) {
		// TODO Auto-generated catch block
		e.printStackTrace();
	} catch (InterruptedException e) {
		// TODO Auto-generated catch block
		e.printStackTrace();
	}

}
//执行main方法生成代码，实体类等
	public static void main(String[] args) {

		MybatisGenTest mybatisGenTest = new MybatisGenTest();
		mybatisGenTest.generator();

	}
}

配置文件

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE generatorConfiguration
PUBLIC "-//mybatis.org//DTD MyBatis Generator Configuration 1.0//EN"
"http://mybatis.org/dtd/mybatis-generator-config_1_0.dtd">
<generatorConfiguration>
	<!-- 数据库驱动包位置 -->
	<classPathEntry
		location="C:/Users/Administrator/eclipse-workspace/Study/src/main/resources/mysql-connector-java-8.0.15.jar"/>
	<context id="sqlGenerate" targetRuntime="MyBatis3">
		<!-- 是否去除自动生成的注释 true：是 ： false:否 -->
		<commentGenerator>
			<property name="suppressAllComments" value="true" />
		</commentGenerator>

		<!-- 数据库链接URL、用户名、密码 -->
		<jdbcConnection driverClass="com.mysql.cj.jdbc.Driver"
			connectionURL="jdbc:mysql://localhost:3306/java4?serverTimezone=GMT%2B8"
			userId="root" password="">
		</jdbcConnection>

		<!-- 默认false，把JDBC DECIMAL 和 NUMERIC 类型解析为 Integer; 为 true时把JDBC DECIMAL和NUMERIC类型解析为java.math.BigDecimal -->
		<javaTypeResolver>
			<property name="forceBigDecimals" value="false" />
		</javaTypeResolver>

		<!-- 生成Pojo包名和位置 -->
		<javaModelGenerator
			targetPackage="com.neuedu.pojo"
			targetProject="/Study/src/main/java">
			<!-- enableSubPackages:是否让schema作为包的后缀 -->
			<property name="enableSubPackages" value="true" />
			<!-- 清理前后的空格 -->
			<property name="trimStrings" value="true" />
		</javaModelGenerator>

		<!-- 生成Mapper映射XML文件位置 -->
		<sqlMapGenerator
			targetPackage="com.neuedu.mapper"
			targetProject="/Study/src/main/java">
			<property name="enableSubPackages" value="true" />
		</sqlMapGenerator>

		<!-- 生成Mapper接口文件位置 -->
		<javaClientGenerator type="XMLMAPPER"
			targetPackage="com.neuedu.mapper"
			targetProject="/Study/src/main/java">
			<property name="enableSubPackages" value="true" />
		</javaClientGenerator>

		<!-- 要生成哪些表(更改tableName和domainObjectName就可以) -->
		<!-- tableName:要生成的表名
		domainObjectName:生成后的实例名
		 enableCountByExample:Count语句中加入where条件查询，默认为true开启
			enableUpdateByExample:Update语句中加入where条件查询，默认为true开启
			 enableDeleteByExample:Delete语句中加入where条件查询，默认为true开启
			enableSelectByExample:Select多条语句中加入where条件查询，默认为true开启
			 selectByExampleQueryId: Select单个对象语句中加入where条件查询，默认为true开启 -->
		<table tableName="t_admin" domainObjectName="Admin"
			enableCountByExample="false" enableUpdateByExample="false"
			enableDeleteByExample="false" enableSelectByExample="false"
			selectByExampleQueryId="false"></table>
		<table tableName="t_user"  domainObjectName="User"
			enableCountByExample="false" enableUpdateByExample="false"
			enableDeleteByExample="false" enableSelectByExample="false"
			selectByExampleQueryId="false"></table>
		<table tableName="t_category"  domainObjectName="Category"
			enableCountByExample="false" enableUpdateByExample="false"
			enableDeleteByExample="false" enableSelectByExample="false"
			selectByExampleQueryId="false"/>
		<table tableName="t_salesorder"  domainObjectName="Salesorder"
			enableCountByExample="false" enableUpdateByExample="false"
			enableDeleteByExample="false" enableSelectByExample="false"
			selectByExampleQueryId="false"/>
		<table tableName="t_product"  domainObjectName="Product"
			enableCountByExample="false" enableUpdateByExample="false"
			enableDeleteByExample="false" enableSelectByExample="false"
			selectByExampleQueryId="false"/>
		<table tableName="t_salesitem"  domainObjectName="Salesitem"
			enableCountByExample="false" enableUpdateByExample="false"
			enableDeleteByExample="false" enableSelectByExample="false"
			selectByExampleQueryId="false"/>
	</context>
</generatorConfiguration>

[weixin_44348990]

已解决，问题在log4j.xml配置文件结尾少了 </log4j:configuration>
新问题：
og4j: reset attribute= "false".
log4j: Threshold ="null".
log4j:WARN No appenders could be found for logger (org.mybatis.generator.internal.db.DatabaseIntrospector).
log4j:WARN Please initialize the log4j system properly.
log4j:WARN See http://logging.apache.org/log4j/1.2/faq.html#noconfig for more info.
