'apc>atsMeasure获取电压、功率值
'E000: Success()
'Source A Freq: 50 Hz
'Source A Voltage: 218 V
'Source B Freq: 50 Hz
'Source B Voltage: 219 V
'Total Output Power: 0.31 kVA
'Source A 24V Power Supply: 24 V
'Source B 24V Power Supply: 24 V
'Source A Boost Voltage: 48 V
'Source B Boost Voltage: 48 V
'3.3V Power Supply: 3.3 V
'1.0V Power Supply: 1.0 V
Dim ATS_T As Boolean = TextStr.Contains("Total Output Power:")
If ATS_T = True Then
Dim temp1, temp2, temp3, temp4, temp5 As String
Dim h1 As Integer
Dim TOP(), tp1(), tp2() As String
TOP = Split(TextStr, vbCrLf) '每-行插入数组
If UBound(TOP) < 12 Then
Exit Sub
End If
For h1 = 0 To UBound(TOP) - 4
temp1 = InStr(1, TOP(h1), "Source A Freq:", 0)
If temp1 > 0 Then
tp1 = Split(TOP(h1).Replace(" ", ""), ":") '去掉空格
tp2 = Split(tp1(1), "Hz")
ATS1_FA = tp2(0) '频率
End If
temp2 = InStr(1, TOP(h1 + 1), "Source A Voltage:", 0)
If temp2 > 0 Then
tp1 = Split(TOP(h1 + 1).Replace(" ", ""), ":")
tp2 = Split(tp1(1), "V")
ATS1_VA = tp2(0) 'a电压
End If
temp3 = InStr(1, TOP(h1 + 2), "Source B Freq:", 0)
If temp3 > 0 Then
tp1 = Split(TOP(h1 + 2).Replace(" ", ""), ":") '去掉空格
tp2 = Split(tp1(1), "Hz")
ATS1_FB = tp2(0) '频率
End If
temp4 = InStr(1, TOP(h1 + 3), "Source B Voltage:", 0)
If temp4 > 0 Then
tp1 = Split(TOP(h1 + 3).Replace(" ", ""), ":") '去掉空格
tp2 = Split(tp1(1), "V")
ATS1_VB = tp2(0) 'b电压
End If
temp5 = InStr(1, TOP(h1 + 4), "Total Output Power:", 0)
If temp5 > 0 Then
tp1 = Split(TOP(h1 + 4).Replace(" ", ""), ":") '去掉空格
tp2 = Split(tp1(1), "kVA")
ATS1_P = tp2(0) '总功率
End If
Next
Dim u1 As Integer
'修改列表值
For u1 = 0 To ListView1.Items.Count - 1
If ListView1.Items(u1).SubItems(2).Text.Trim = IPPORT Then '连接参数
ListView1.Items(u1).SubItems(3).Text = ATS1_FA & "Hz/" & ATS1_VA & "V" 'A路电压
ListView1.Items(u1).SubItems(4).Text = ATS1_FB & "Hz/" & ATS1_VB & "V" 'B路电压
ListView1.Items(u1).SubItems(5).Text = ATS1_P & "kVA" '总功率
If IsNumeric(ATS1_P) = True And IsNumeric(ATS1_VA) = True Then
ListView1.Items(u1).SubItems(6).Text = Int(ATS1_P * 1000 / Int(ATS1_VA) * 100) / 100 & "A" '电流
Else
ListView1.Items(u1).SubItems(6).Text = " A"
End If
ListView1.Items(u1).SubItems(13).Text = TimeOfDay() '更新时间
ListView1.Items(u1).SubItems(15).Text = "atsMeasure"
TxtBox_S1.Text = ATS1_P & "* 1000 /" & ATS1_VA & " * 100) / 100 A" & vbCrLf & TxtBox_S1.Text
End If
Next
'发送查询
dic(IPPORT).Send(Encoding.Default.GetBytes("atsStatus"))
'发送回车键
ent(dic(IPPORT))
End If
'apc>atsStatus 获取状态
'E000: Success
'Communication Status: OK
'Selected Source: Source A
'Preferred Source: Source A
'Switch Status: OK
'Front Panel: Unlocked
'Source A: Selected
'Source B: OK
'Phase Synchronization: Out of sync
'Source A 24V Power Supply: OK
'Source B 24V Power Supply: OK
'Source A Boost Voltage: OK
'Source B Boost Voltage: OK
'3.3V Power Supply: OK
'1.0V Power Supply: OK
Dim ATS_S As Boolean = TextStr.Contains("Selected Source:")
If ATS_S = True Then
Dim temp1, temp2, temp3, temp4, temp5 As String
Dim h As Integer
Dim SS(), tp1() As String
SS = Split(TextStr, vbCrLf) '每-行插入数组
If UBound(SS) < 13 Then
Exit Sub
End If
For h = 0 To UBound(SS) - 5
temp1 = InStr(1, SS(h), "Selected Source:", 0)
If temp1 > 0 Then
'TextBox1.Text = TextBox1.Text & vbCrLf & SS(h) '获取整行
tp1 = Split(SS(h), ":")
ATS1_Selected = LTrim(tp1(1)) '在线选路
End If
temp2 = InStr(1, SS(h + 1), "Preferred Source", 0)
If temp2 > 0 Then
tp1 = Split(SS(h + 1), ":")
ATS1_Preferred = LTrim(tp1(1)) '优先选路
End If
temp3 = InStr(1, SS(h + 2), "Switch Status", 0)
If temp3 > 0 Then
tp1 = Split(SS(h + 2).Replace(" ", ""), ":")
ATS1_Switch = tp1(1) '开关状态
End If
'temp1 = InStr(1, SS(h), "Communication Status:", 0)
'If temp1 > 0 Then
' tp1 = Split(SS(h).Replace(" ", ""), ":")
' ATS1_C = tp1(1) '通信状态
'End If
temp4 = InStr(1, SS(h + 4), "Source A:", 0)
If temp4 > 0 Then
tp1 = Split(SS(h + 4).Replace(" ", ""), ":")
tempA = tp1(1) 'A路状态
End If
temp5 = InStr(1, SS(h + 5), "Source B:", 0)
If temp5 > 0 Then
tp1 = Split(SS(h + 5).Replace(" ", ""), ":")
tempB = tp1(1) 'B路状态
End If
Next
'修改列表值
Dim u2 As Integer
For u2 = 0 To ListView1.Items.Count - 1
If ListView1.Items(u2).SubItems(2).Text.Trim = IPPORT Then '连接参数
ListView1.Items(u2).SubItems(7).Text = ATS1_Preferred '优先线路
ListView1.Items(u2).SubItems(8).Text = ATS1_Selected '当前选择
ListView1.Items(u2).SubItems(9).Text = tempB '备路状态
ListView1.Items(u2).SubItems(10).Text = ATS1_Switch '开关状态
ListView1.Items(u2).SubItems(13).Text = TimeOfDay() '更新时间
ListView1.Items(u2).SubItems(15).Text = "atsStatus"
'判断是否切换
If ATS1_Selected <> ATS1_Preferred Then
ListView1.Items(u2).BackColor = Color.Red
'写日志
'logfilepath = logdirpath1 + "\" & Now.Year & "-" & Now.Month & "-" & Now.Day & "ERRLOG.txt"
'writelogdata(logfilepath, Now & " " & IPPORT & "设备当前选择异常:" & ATS1_Preferred & "。")
INFO_SSLable.Text = Now & " " & IPPORT & "设备当前选择:" & ATS1_Preferred & "。"
TextBox1.Text = Now & " " & IPPORT & "设备当前选择:" & ATS1_Preferred & "。" & vbCrLf & TextBox1.Text
Else
ListView1.Items(u2).BackColor = btncr
End If
'判断备路状态
If tempB <> "OK" Then
ListView1.Items(u2).BackColor = Color.Red
'写日志
'logfilepath = logdirpath1 + "\" & Now.Year & "-" & Now.Month & "-" & Now.Day & "ERRLOG.txt"
'writelogdata(logfilepath, Now & " " & IPPORT & "设备备路状态异常:" & tempB & "。")
INFO_SSLable.Text = Now & " " & IPPORT & "设备备路状态异常:" & tempB & "。"
TextBox1.Text = Now & " " & IPPORT & "设备备路状态异常:" & tempB & "。" & vbCrLf & TextBox1.Text
Else
ListView1.Items(u2).BackColor = btncr
End If
'判断开关状态
If ATS1_Switch <> "OK" Then
ListView1.Items(u2).BackColor = Color.Red
''写日志
'logfilepath = logdirpath1 + "\" & Now.Year & "-" & Now.Month & "-" & Now.Day & "ERRLOG.txt"
'writelogdata(logfilepath, Now & " " & IPPORT & "设备开关状态异常:" & ATS1_Switch & "。")
INFO_SSLable.Text = Now & " " & IPPORT & "设备开关状态异常:" & ATS1_Switch & "。"
TextBox1.Text = Now & " " & IPPORT & "设备开关状态异常:" & ATS1_Switch & "。" & vbCrLf & TextBox1.Text
Else
ListView1.Items(u2).BackColor = btncr
End If
End If
Next
End If
'连接ATS设备,连接函数
Private Sub con_ats_ipport(ByVal Str As String)
Dim i As Integer
Dim atsname, con_ipport, ipport() As String
For i = 0 To ListView1.Items.Count - 1
If ListView1.Items(i).SubItems(12).Text.Trim = Str Then
Try
atsname = ListView1.Items(i).SubItems(1).Text 'ATS名称
con_ipport = ListView1.Items(i).SubItems(2).Text '连接参数
ipport = Split(con_ipport, ":")
'现在尝试连接atsname服务端,ipport(0)为IP,ipport(1)为端口
TextBox1.Text = Now & " 现在连接" & atsname & "。" & vbCrLf & TextBox1.Text
Dim siteResponds As Boolean = False
siteResponds = My.Computer.Network.Ping(ipport(0)) 'ping IP地址查看是否可用
If siteResponds = False Then
ListView1.Items(i).SubItems(12).Text = "连接失败"
TextBox1.Text = Now & " " & atsname & "的IP地址不可用。" & vbCrLf & TextBox1.Text
'写日志
'logfilepath = logdirpath1 + "\" & Now.Year & "-" & Now.Month & "-" & Now.Day & "LOG.txt"
'writelogdata(logfilepath, Now & " " & atsname & "的IP地址不可用。")
Else
Dim localEndPoint1 As New IPEndPoint(IPAddress.Parse(ipport(0)), ipport(1))
ListenSocket = New Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp)
ListenSocket.Connect(localEndPoint1)
If ListenSocket.Connected = True Then
dic.Add(ListenSocket.RemoteEndPoint.ToString, ListenSocket)
'禁用线程检测
Control.CheckForIllegalCrossThreadCalls = False
'创建一个线程用于接收数据
LinkThread = New Thread(AddressOf ReciveData)
'设置为后台进程
LinkThread.IsBackground = True
LinkThread.Start(ListenSocket)
ComboBox_Socket.Items.Add(ListenSocket.RemoteEndPoint.ToString) '把连接到的服务端IP和端口存到下拉框里
ListView1.Items(i).SubItems(12).Text = "已连接"
ConLis = True
TextBox1.Text = Now & " " & atsname & "连接成功。" & vbCrLf & TextBox1.Text
'写日志
logfilepath = logdirpath1 + "\" & Now.Year & "-" & Now.Month & "-" & Now.Day & "LOG.txt"
writelogdata(logfilepath, Now & " " & atsname & "端口连接成功。")
Else
ListView1.Items(i).SubItems(12).Text = "连接失败"
TextBox1.Text = Now & " " & atsname & "端口连接失败。" & vbCrLf & TextBox1.Text
'写日志
logfilepath = logdirpath1 + "\" & Now.Year & "-" & Now.Month & "-" & Now.Day & "LOG.txt"
writelogdata(logfilepath, Now & " " & atsname & "端口连接失败。")
End If
Thread.Sleep(200)
End If
Catch ex As Exception
logfilepath = logdirpath1 + "\" & Now.Year & "-" & Now.Month & "-" & Now.Day & "ERRLOG.txt"
writelogdata(logfilepath, Now & " " & Str & "错误:" & ex.Message)
TextBox1.Text = Now & " " & Str & vbCrLf & TextBox1.Text
End Try
End If
Next
End Sub
'侦听线程,接收数据
Private Sub ReciveData(ByVal s As Object)
While True
Dim Socketcon As Socket
Socketcon = s
If ConLis = True Then
Dim bytes(4096) As Byte
Dim p() As String
Dim NumGet As Integer = Socketcon.Receive(bytes)
If Encoding.Default.GetString(bytes, 0, NumGet).Length > 0 Then
p = Split(Socketcon.RemoteEndPoint.ToString, ":")
If p(1) = ATSGroup(0, 1) Then‘端口为2000
'显示服务端发来的消息
Receive_TXT11.Text = Now & vbCrLf & Socketcon.RemoteEndPoint.ToString & vbCrLf & Encoding.Default.GetString(bytes, 0, NumGet)
Else
'显示服务端发来的消息,端口为3000
Receive_TXT12.Text = Now & vbCrLf & Socketcon.RemoteEndPoint.ToString & vbCrLf & Encoding.Default.GetString(bytes, 0, NumGet)
End If
'sqlstr = "INSERT INTO ats_history(ipport,re_time,re_data)VALUES('" & Socketcon.RemoteEndPoint.ToString & "', '" & Now & "', '" & Encoding.Default.GetString(bytes, 0, NumGet) & "')"
'If InsertRow(sqlstr) Then
' 'MessageBox.Show(LocalIP, "ok", MessageBoxButtons.OK)
'End If
End If
End If
End While
End Sub
Private Sub Timer1_Tick(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles Timer1.Tick
ToolStripStatusLabel2.Text = Now '状态栏显示系统时间
'0点刷新清空日志
If TimeOfDay = "0:00:01" Then
TextBox1.Text = Now & " "
End If
'初始连接ATS采集盒
If ConLis = False Then
con_ats_ipport("端口启用")
End If
'有连接失败,重新连接,5秒检查一次
If Conlis_F_time <> 0 Then
Conlis_F_time = Conlis_F_time - 1
Else
con_ats_ipport("连接失败")
End If
End Sub
收到的数据进行处理
'处理接收到的数据
Private Sub Receive_TXT11_TextChanged(ByVal sender As Object, ByVal e As System.EventArgs) Handles Receive_TXT11.TextChanged
If Receive_TXT11.Text.Trim = "" Then
Exit Sub
End If
TextBox2.Text = Receive_TXT11.Lines(1).Trim
Dim line As String = Receive_TXT11.Text.Trim
Dim ATS_u As Boolean = line.Contains("User Name")
Dim ATS_p As Boolean = line.Contains("Password")
Dim ATS1_OK As Boolean = line.Contains("Super User") '登录成功'型号AP4423
Dim ATS2_OK As Boolean = line.Contains("Administrator") '型号AP7723
Dim ATS1_OKed As Boolean = line.Contains("apc>") '已登录过
Dim ATS2_OKed As Boolean = line.Contains("--- Control Console ---") '型号AP7723
Dim ATS_by As Boolean = line.Contains("Bye.") '退出 ,则重新登录
Dim ATS2_by As Boolean = line.Contains("Logging out") '型号AP7723
Dim ESC_b As Boolean = line.Contains("<ESC>-")
Dim ATS2_h As Boolean = line.Contains("----")
Dim ATS2_DM As Boolean = line.Contains("-- Device Manager --")
Dim ATS_SNMP As Boolean = line.Contains("-- SNMP --")
ATS1_IPPORT = Receive_TXT11.Lines(1).Trim '获取选定的客户端IP地址和端口
'Try
'发送登录用户和密码apc
If ATS_u = True Or ATS_p = True Then
dic(ATS1_IPPORT).Send(Encoding.Default.GetBytes("apc"))
'发送回车键
ent(dic(ATS1_IPPORT))
End If
'登录成功
If ATS1_OK = True Or ATS2_OK = True Or ATS1_OKed Or ATS2_OKed Then
Dim g As Integer
For g = 0 To ListView1.Items.Count - 1
If ListView1.Items(g).SubItems(2).Text.Trim = ATS1_IPPORT And ListView1.Items(g).SubItems(12).Text = "已连接" Then
ListView1.Items(g).SubItems(12).Text = "登录成功"
TextBox1.Text = Now & " " & ListView1.Items(g).SubItems(1).Text.Trim & "设备登录成功,查询设备信息。" & vbCrLf & TextBox1.Text
'写日志
'logfilepath = logdirpath1 + "\" & Now.Year & "-" & Now.Month & "-" & Now.Day & "LOG.txt"
'writelogdata(logfilepath, Now & " " & ListView1.Items(j).SubItems(1).Text.Trim & "设备登录成功。")
''型号AP4423,AP7723
If ListView1.Items(g).SubItems(14).Text.Trim = "AP4423" Then
dic(ATS1_IPPORT).Send(Encoding.Default.GetBytes("aboutATS"))
'发送回车键
ent(dic(ATS1_IPPORT))
ListView1.Items(g).SubItems(15).Text = "aboutATS"
Thread.Sleep(100)
ElseIf ListView1.Items(g).SubItems(14).Text.Trim = "AP7723" Then
dic(ATS1_IPPORT).Send(Encoding.Default.GetBytes("1"))
'发送回车键
ent(dic(ATS1_IPPORT))
Thread.Sleep(100)
dic(ATS1_IPPORT).Send(Encoding.Default.GetBytes("8"))
'发送回车键
ent(dic(ATS1_IPPORT))
ListView1.Items(g).SubItems(15).Text = "8"
End If
End If
'Thread.Sleep(100)
Next
LoginLis = True
End If
。。。。。。
