关于.net WebBrowser.DrawToBitmap方法去截图地图html页面不成功

平山CP3 2021-02-09 06:10:15
使用WebBrowser.DrawToBitmap,在winform的webbrowser去加载有地图的页面能加载出来,但是像地图页面截出来的图片却是空白的。

截图百度地图样例:
...全文
186 2 打赏 收藏 转发到动态 举报
AI 作业
写回复
用AI写文章
2 条回复
切换为时间正序
请发表友善的回复…
发表回复
平山CP3 2021-02-09
  • 打赏
  • 举报
回复
引用 1 楼 以专业开发人员为伍的回复:
WebBrowser 控件有可能只是适用于最传统的 html element,例如 <img> 之类的。对于使用 canvas 或者 svg 画图的可能无效。你可以使用 WebBrowser 功能来返回具体的 <div> 的窗口坐标(x,y),然后调用 windows SDK 兼容的截屏功能来录制图片。使用更好的 web 控件,可以捕获的更好。
大神居然来回帖,感谢,那也就是webbrowser去画图有canvas这种html不太行是吗,可是在可视化窗口中也确实完全加载出来了,只是drawtobigmap时候绘不出来吗
  • 打赏
  • 举报
回复
WebBrowser 控件有可能只是适用于最传统的 html element,例如 <img> 之类的。对于使用 canvas 或者 svg 画图的可能无效。你可以使用 WebBrowser 功能来返回具体的 <div> 的窗口坐标(x,y),然后调用 windows SDK 兼容的截屏功能来录制图片。使用更好的 web 控件,可以捕获的更好。
